In the industrial production process, the use of synchronous belt transmission is very much, synchronous belt can be divided into two types according to the material, one is polyurethane synchronous belt and the other is rubber synchronous belt, the material is different, the performance of the product is also different

Rubber timing belt is made of high quality neoprene imported from Japan as the main raw material, with a variety of accessories for different purposes. The skeleton material adopts high quality glass fiber rope imported from Japan. The toothed surface is protected by nylon 66 high elastic canvas. The glass fiber strength layer is a rope formed by spirally winding multiple strands of glass fibers along the width of the tape at node positions. It has the characteristics of high strength, low elongation, corrosion resistance and heat resistance. The neoprene tape backing is firmly bonded to the node line locations by means of glass fiber, which acts as a protective layer. The belt teeth are made of nylon canvas with good wear resistance and neoprene with high shear strength and suitable hardness. It needs to be precisely shaped and precisely positioned to mesh correctly with the pulley teeth, and its roots need to be kept at a certain distance from the pitch line to ensure that there is no change in bending.
