Characteristics:
1.HPL High Performance Steel Wire Core Polyurethane Timing Belt
2.A tooth profile according to S017396
3.Metric pitch 5mm
4.One designed for linear drives
5.A synchronous belt allowable tensile load is higher than the standard product,so the elongation is lower.
6.Special pretension and pitch tolerance control ensure high precision positioning in linear drives
7.Negative length tolerance available on request

Characteristics:
1.Wire core polyurethane synchronous belt
2.Tooth shape in accordance with 1S017396
3.Metric pitch 2.5 mm
4.For drive solutions with high flexibility requirements
5.Widely used in conveyor,linear drive and light duty power transmission applications
6.Color:white

Characteristics:
1.Wire core polyurethane synchronous belts
2.Tooth profile according to 1S017396 standard
3.Metric pitch 10mm
4.For drive solutions with high flexibility requirements
5.Widely used in conveyor,linear drive and medium duty power transmission applications
6.Polyurethane synchronous belts with double-sided teeth available

Characteristics:
1.Polyurethane synchronous belts with steel cores
2.Tooth profile according to IS0 17396
3.Metric pitch 20mm
4.For drive solutions with high flexibility requirements
5.Widely used in conveyor,linear drive and light-duty power transmission applications
6.Polyurethane synchronous belts with steel cores and double-sided teeth available
